Where can I download User Manual

Voo 4 years ago in Equipment updated by Support Manager 6 days ago 1
Where can I download manuals?
Answer
Support Manager 6 days ago

Інструкції українською:

Инструкции на русском:

English version of User Guide:

Додаткові інструкції:

Дополнительные инструкции:

Additional instructions:

0
Answered

Использование данных для вычислений

Сергей 2 months ago in Tips and Tricks updated by Support Manager 2 months ago 1

Доброго дня!

Можно ли как то использовать для дальнейших расчетов данные, накопленные за минуту, час и тд?!

Если да, то как получить к ним доступ для вставки в формулы, какую указывать переменную ибо в доступных данных их нет (нужно для получения среднего расхода измеряемой среды за период времени)

0
Completed

HOW-TO: Smart-MAIC D105 with Open Energy monitor sensor and Home Assistant

Mika 2 months ago in Tips and Tricks updated 2 months ago 2

Hello,

did lot of searching in Internet, but didn't find any guides how to set up Smart-MAIC D105 pulse counter with Home Assistant and Open Energy Monitor sensor. Open energy monitor is sensor that counts pulses from utility company kWh-meter and as such, it can be [legally] installed without being electrician and removing panels from electric cabinet (which I still did, as I needed to wire Cat5 for sensor neatly). It also shows exactly same consumption utility compay is charging, since it's read from "official" energy meter. Also, you may avoid need to re-seal electric cabinet, since installing measurement coils may require opening sealed cabinet parts.

My config in Home Assistant sensor.yaml is following:

- platform: mqtt
  name: "kWh-mittari"
  unique_id: 'smartmaic_myunitnumber'
  state_topic: "myunitnumber/JSON"
  unit_of_measurement : "kWh"
  device_class: energy
  state_class: total_increasing
  value_template: '{{ value_json.TCh1 | float * 0.001 }}'

My energy meter sends 1000 pulses for every consumed 1kWh, therefore, value template uses float * 0.001. Some meters use other values, like 800 pulses / 1 kWh, then this value template probably would be float * 0.0125. For this config to work, you need to:

1. configure MQTT server in your Home Assistant (I'm using Mosquitto)

2. configure MQTT in Smart-MAIC D105 (there's page for it)

With this config you can see hourly, daily, weekly, monthly etc consumption in your Home Assistant energy page. Add your electric price, it will count costs. When you adjust price, old values will be retained and only new consumption values get new price (likely higher...)


There's in no need to change default Smart-MAIC D105 pulse counter settings! Just make sure Mode of operation-setting is Pulse counter.


Open Energy Monitor-sensor is to be connected to digital input lines, with three wire:

- OpenEnergy Monitor red, VCC - Smart-MAIC contact 5

- OpenEnergy Monitor blue, TTL Data - Smart-MAIC contact 2

- OpenEnergy Monitor black, GND - Smart-MAIC contact 1

(This config is called NPN-counter in Smart-MAIC documentation)
There is no need to additional electronic components (resistors etc.). I'm using unshielded Cat5e as signal cable, sensor is about 15m from counter and works well with Cat5e.

0
Answered

Чи у всіх девайсів є modbus?

Євген 3 months ago in Equipment updated by Support Manager 3 months ago 1

Чи можна WiFi smart-MAC D103 і WiFi smart-MAC D101 використати без wifi, тільки по modbus?

Потрібно використовувати для проекта де є самостійний девайс з wifi і ще кипою інших датчиків і потрібен тільки девайс що міряє напругу і струм по modbus/uart.

0
Answered

Показания по тарифам

Ivan 1 year ago in Dashboard and Widgets updated by Support Manager 3 months ago 5

Здравствуйте.

Надоело бегать каждый месяц в щитовую - снимать показания.

Подскажите, как реализовать виджет, который бы отображал показания с двухтарифного счетчика в дашборде?

Сейчас показания счетчика в щитовой:

день - 4604

ночь - 6205

Спасибо!
